● The control panel of the WinLC RTX controller is open.
● In the dialog box of the "Set PC Station" configuration console, the PC station access point
of SIMATIC PCS 7 AS mEC RTX is set to "S7ONLINE: = PC internal (local)".
Procedure
1. If the CPU is in the RUN operating mode, select the menu command CPU > STOP in the
operator panel of the CPU.
The user program running on the CPU is stopped.
2. Start the Station Configuration Editor with the menu command Start > Station Configuration
Editor.
3. Click "Station Name". Enter the name of the SIMATIC PCS 7 AS mEC RTX.
Note
This station name must match the project-specific name of the PC station in the PCS 7
project.
4. Insert the missing components in the Station Configuration Editor (see table):
HW Config Station Configuration Editor ("Components" tab)
Index Module Index Name Type
1 1
2
IF1 X1
X1 P1 R
X2 P1 R
IF2
IF3
IF4
WinLC RTX EC
PN-IO
Port 1
Port 2
2
IF1
WinLC RTX
CP 1616/ERTEC400_EC
WinLC RTX
3 IE_General 3 IE_General IE_General
5. Click "Add..." to add missing components.
The "Add Component" dialog box opens.
6. Select the entry "IE_General" from the list and set the same index (slot number) which you
have set for the component in HW Config.
7. In the list, select the entry "WinLC RTX". Click "Edit".
The "Edit Component" dialog box opens.
8. Click "Properties".
The "WinLC properties" dialog box opens.
9. In the "Available cards" group mark the "CP 1616/ERTEC400_EC" and drag&drop it onto
the interface slot (IF1).
10.Click the "Confirm and restart the CPU" button. The settings are applied and the controller
are restarted.
11.Click "OK".
The "WinLC properties" dialog box closes.
Commissioning and configuring SIMATIC PCS 7 AS mEC RTX
9.10 How to set the components on the SIMATIC PCS 7 AS mEC RTX
BOX (V8.1)
108 Function Manual, 03/2015, A5E32711362-AC
