Requirements
● Automation License Manager is installed on the engineering station and the SIMATIC
PCS 7 BOX PC.
● SIMATIC Manager is open and your PCS 7 project is displayed in the Component view.
● The CPU is in STOP mode.
● The menu command PLC > Download to Current Project > Selected Connections has been
executed in NetPro for a selected SIMATIC station.
Note
During the first download operation, the CPU has to be in STOP mode.
The CPU behaves like a standard CPU in PCS 7.
The CPU of the SIMATIC PCS 7 BOX RTX cannot be configured in RUN.
Procedure
1. Select the project in the component view.
2. Select the menu command PLC > Compile and Download Objects..
The "Compile and Download Objects" dialog box opens.
3. Click the plus icon to open all objects in the dialog box.
4. In the tree view of the SIMATIC PC station of SIMATIC PCS 7 BOX, select the
"Configuration" object and select the check boxes in the "Compile" and "Download"
columns.
5. In the tree view of the SIMATIC PC station of SIMATIC PCS 7 BOX, select the "Charts"
object and select the check boxes in the "Compile" and "Download" columns.
6. Click "Edit" in the "Settings for Compilation/Download" group.
The "Compile Program/download to target system" dialog box opens.
– Select the "Compile Charts as Program" tab, then click "Entire program" in the "Scope"
group.
– Select the "S7 Download" tab, then click "Entire program" in the "Download mode" group.
7. Click "OK" to close the "Compile program/download to target system" dialog box.
8. In the tree view of the SIMATIC PC station of SIMATIC PCS 7 BOX, select the "OS..." object
and select the check boxes in the "Compile" and "Download" columns.
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.4 Configuring SIMATIC PCS 7 BOX RTX with external engineering
BOX (V8.1)
70 Function Manual, 03/2015, A5E32711362-AC
