Siemens SIMOTICS L-1FN3 Configuration Manual

Configuration
5.4 Mounting
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
143
5.4.4.1
Comply with the installation dimensions
Installation dimensions for the motor installation
The following figure shows the installation dimensions for the motor installation. The
associated values are specified in the following table.
Figure 5-20 Installation dimensions for the motor installation
Peak load motor: Installation dimensions
Table 5- 3 Installation dimensions for installing the motor according to figure above
Installation dimen-
sion with precision
cooler and with
secondary section
cooler
Installation dimen-
sion with precision
cooler and without
secondary section
cooler
Installation dimen-
sion without preci-
sion cooler and
without secondary
section cooler
Installation dimen-
sion without preci-
sion cooler but with
secondary section
cooler
Tolerance of
the installation
dimensions
1FN3..-xW
h
M1
in mm
h
M2
in mm
h
M3
in mm
h
M4
in mm
in mm
1FN3050
1FN3100
63.4 60.4 48.5 51.1 +0.3
1FN3150
65.4
62.4
50.5
53.5
+0.3
1FN3300
79.0
76.0
64.1
67.1
+0.3
1FN3450
81.0
78.0
66.1
69.1
+0.3
1FN3600
86.0
--
--
74.1
+0.3
1FN3900
88.0
--
--
76.1
+0.3
