Siemens SIMOTICS L-1FN3 Configuration Manual

Technical data and characteristics
6.2 Data sheets and characteristics
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
303
6.2.5
1FN3450-xxxxx-xxxx
Data sheet of 1FN3450-1NB50-0xAx
1FN3450-1NB50-0xAx
Technical data
Designation
Unit
Value
General conditions
DC-link voltage
U
DC
V
600
Water cooling flow temperature
T
VORL
°C
35
Rated temperature
T
N
°C
120
Data at the rated point
Rated force
F
N
N
1300
Rated current
I
N
A
9.1
Maximum velocity at rated force
v
MAX,FN
m/min
169
Rated power loss
P
V,N
kW
0.693
Limit data
Maximum force
F
MAX
N
2200
Maximum current
I
MAX
A
19.1
Maximum velocity at maximum force
v
MAX,FMAX
m/min
93.5
Maximum electric power drawn
P
EL,MAX
kW
6.49
Static force
F
0
*
N
932
Stall current
I
0
*
A
6.44
Physical constants
Force constant at 20 °C
k
F,20
N/A
145
Voltage constant
k
E
Vs/m
48.4
Motor constant at 20 °C
k
M,20
N/W
0.5
59.2
Motor winding resistance at 20 °C R
STR,20
Ω 2
Phase inductance L
STR
mH 50.6
Attraction force F
A
N 4340
Thermal time constant
t
TH
s
180
Pole width τ
M
mm 23
Mass of the primary section
m
P
kg
12
Mass of the primary section with precision cooler
m
P,P
kg
12.8
Mass of a secondary section m
S
kg 3.8
Mass of a secondary section with heatsink profiles
m
S,P
kg
4
Primary section main cooler data
Maximum dissipated thermal output
Q
P,H,MAX
kW
0.614
Recommended minimum volume flow rate
V
P,H,MIN
l/min
3.5
Coolant temperature rise
ΔT
P,H
K
2.52
Pressure drop
Δp
P,H
bar
0.166
