Siemens SIMOTICS L-1FN3 Configuration Manual

Technical data and characteristics
6.1 Explanations
1FN3 linear motors
166 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
6.1
Explanations
6.1.1
Explanations of the formula abbreviations
Data sheet contents
The data contained in the data sheets are explained in the following and divided as follows:
● General conditions
● Data at the rated point
● Limit data
● Physical constants
● Primary section main cooler data
● Primary section precision cooler data
● Secondary section cooling data
General conditions
U
DC
Converter DC link voltage (direct voltage value).
Comment
: U
a max
is the maximum permissible converter output voltage
T
VORL
Maximum flow temperature of the water cooling if the motor is to be utilized up to its rated force F
N
.
T
N
Rated temperature of the motor winding
Ratings (S1 duty)
F
N
Rated force of the motor
I
N
Rated current of the motor at rated force F
N
v
MAX, FN
Maximum velocity up to which the motor can deliver the rated force F
N
P
V,N
Motor power loss at the rated point (F
N
,v
MAX,FN
) at the rated temperature T
N
. Losses due to friction and
eddy currents are ignored.
Comment:
The power loss is calculated using P
V
= 3·R
STR
(T)·I
2
. Correspondingly, P
V,N
is calculated
using P
V,N
= 3·R
STR
(T
N
)·I
N
2
.
