Description of the motor
2.3 Technical features and environmental conditions
1FN3 linear motors
38 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Supplied pictograms
Primary sections
To identify hazards, warning signs in the form of permanent adhesive stickers are enclosed
with all primary sections in the packaging:
Table 2- 3 Warning signs included with primary sections according to BGV A8 and EN ISO 7010
and their meaning
Warning against
hot surface
(W017)
Warning against
electric voltage
(W012)
The following safety instructions are attached at the signal port of the primary section:
Table 2- 4 Safety instructions for temperature protection according to BGV A8 and EN ISO 7010
and their significance
General
warning sign
(W001)
Observe
instruction
(M002)
To identify hazards, warning and prohibition signs in the form of permanent adhesive stickers
are enclosed with all secondary sections in the packaging:
Table 2- 5 Warning signs according to BGV A8 and EN ISO 7010 included with secondary sections
and their meaning
Warning: strong
magnetic field
(W006)
Warning:
hand injuries
(W024)
