Description of the motor
2.1 Highlights and benefits
1FN3 linear motors
24 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Overview of the connection variants
Peak and continuous load motor
-assembled cables
Peak and continuous load motor
with connection cover for two cables
with connector cover for one cable
with a fixed cable without a connector
The general-purpose motors in the 1FN3 product family are powerful linear motors with a
broad range of types. These motors have the following properties:
● High power density
● High dynamic response
● High forces
● Compact design
● Low sensitivity to corrosive ambient conditions
While the peak load motors have high overload capability, the continuous load motors have
a rated force with high availability.
The motors of the 1FN3 product family can be operated in parallel. You will find information
on this in Chapter "Coupled motors (Page 569)".
