1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
3
This documentation only describes the functionality of the standard version. The machine
OEM documents any extensions or changes to the motor made by it.
For reasons of clarity, this documentation cannot contain all of the detailed information on all
of the product types. Moreover, this documentation cannot take into consideration every
possible type of installation, operation, and maintenance.
This documentation should be kept in a location where it can be easily accessed and made
available to the personnel responsible.
This manual is aimed at planning, project, and design engineers as well as electricians,
fitters, and service personnel.
This manual provides information on the rules and guidelines that must be observed when
configuring a system with motors from the 1FN3 product family. It also helps with the
selection of peak and continuous load motors within this range.
In addition to the notes that you must observe for your own personal safety as well as to
avoid material damage, in this document you will find the following text features:
Operating instructions with the specified sequence are designated using the following
symbols:
The arrow indicates the start of the operating instructions.
The individual handling steps are numbered.
1. Execute the operating instructions in the specified sequence.
The square indicates the end of the operating instruction.
Operating instructions without a specified sequence are identified using a bullet point:
● Execute the operating instructions.
