Siemens SIMOTICS L-1FN3 Configuration Manual

Technical data and characteristics
6.2 Data sheets and characteristics
1FN3 linear motors
304 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
1FN3450-1NB50-0xAx
Technical data
Designation
Unit
Value
Primary section precision cooler data
Maximum dissipated thermal output
Q
P,P,MAX
kW
0.0182
Recommended minimum volume flow rate
V
P,P,MIN
l/min
3.5
Pressure drop
Δp
P,P
bar
0.19
Secondary section cooling data
Maximum dissipated thermal output
Q
S,MAX
kW
0.0609
Recommended minimum volume flow rate
V
S,MIN
l/min
3.5
Pressure drop per meter of heatsink profile
Δp
S
bar
0.0724
Pressure drop per combi distributor
Δp
KV
bar
0.324
Pressure drop per coupling point
Δp
KS
bar
0.237
