Siemens SIMOTICS L-1FN3 Configuration Manual

Technical data and characteristics
6.2 Data sheets and characteristics
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
229
1FN3150-1WC00-0xAx
Technical data
Designation
Unit
Value
Primary section precision cooler data
Maximum dissipated thermal output
Q
P,P,MAX
kW
---
Recommended minimum volume flow rate
V
P,P,MIN
l/min
---
Pressure drop
Δp
P,P
bar
---
Secondary section cooling data
Maximum dissipated thermal output
Q
S,MAX
kW
0.0283
Recommended minimum volume flow rate
V
S,MIN
l/min
2.8
Pressure drop per meter of heatsink profile
Δp
S
bar
0.0482
Pressure drop per combi distributor
Δp
KV
bar
0.209
Pressure drop per coupling point
Δp
KS
bar
0.154
