Siemens SIMOTICS L-1FN3 Configuration Manual

Technical data and characteristics
6.2 Data sheets and characteristics
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
297
Data sheet of 1FN3300-3NC40-0xAx
1FN3300-3NC40-0xAx
Technical data
Designation
Unit
Value
General conditions
DC-link voltage
U
DC
V
600
Water cooling flow temperature
T
VORL
°C
35
Rated temperature
T
N
°C
120
Data at the rated point
Rated force
F
N
N
2590
Rated current
I
N
A
27.3
Maximum velocity at rated force
v
MAX,FN
m/min
252
Rated power loss
P
V,N
kW
1.52
Limit data
Maximum force
F
MAX
N
4400
Maximum current
I
MAX
A
57.4
Maximum velocity at maximum force
v
MAX,FMAX
m/min
139
Maximum electric power drawn
P
EL,MAX
kW
16.9
Static force
F
0
*
N
1860
Stall current
I
0
*
A
19.3
Physical constants
Force constant at 20 °C
k
F,20
N/A
96.7
Voltage constant
k
E
Vs/m
32.2
Motor constant at 20 °C
k
M,20
N/W
0.5
80.1
Motor winding resistance at 20 °C R
STR,20
Ω 0.486
Phase inductance L
STR
mH 11.8
Attraction force F
A
N 8670
Thermal time constant t
TH
s 180
Pole width
τ
M
mm
23
Mass of the primary section
m
P
kg
23
Mass of the primary section with precision cooler m
P,P
kg 24.4
Mass of a secondary section
m
S
kg
2.4
Mass of a secondary section with heatsink profiles
m
S,P
kg
2.6
Primary section main cooler data
Maximum dissipated thermal output
Q
P,H,MAX
kW
1.34
Recommended minimum volume flow rate
V
P,H,MIN
l/min
4.5
Coolant temperature rise
ΔT
P,H
K
4.29
Pressure drop
Δp
P,H
bar
0.56
Primary section precision cooler data
Maximum dissipated thermal output
Q
P,P,MAX
kW
0.0397
Recommended minimum volume flow rate
V
P,P,MIN
l/min
4.5
Pressure drop
Δp
P,P
bar
0.527
