Technical data and characteristics
6.2 Data sheets and characteristics
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
373
1FN3600-2WA50-0xAx
Technical data
Designation
Unit
Value
Primary section precision cooler data
Maximum dissipated thermal output
Q
P,P,MAX
kW
0.0573
Recommended minimum volume flow rate
V
P,P,MIN
l/min
4.5
Pressure drop
Δp
P,P
bar
0.839
Secondary section cooling data
Maximum dissipated thermal output
Q
S,MAX
kW
0.184
Recommended minimum volume flow rate
V
S,MIN
l/min
4.5
Pressure drop per meter of heatsink profile
Δp
S
bar
0.0165
Pressure drop per combi distributor
Δp
KV
bar
0.113
Pressure drop per coupling point
Δp
KS
bar
0.12
