Preparation for use
7.1 Transporting
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
477
Table 7- 6 Packaging specifications for 1FN3xxx-xSxxx-xxxx secondary sections
Not subject to notification
and labeling requirements
Subject to notification and
labeling requirements
A single secondary section is
packaged in its original
X
Two secondary sections
each are packaged in the
original individual packaging
and correctly stacked in pairs
X
2
)
Secondary sections are
packaged in the original
individual packaging and can
X
1
)
) If the secondary section is also packed in a ferromagnetic sheet metal case in addition to the original individual
packaging, e.g. manufactured out of iron with a thickness of greater than 0.5 mm, then when shipping, you only have to
notify the relevant authorities and attach appropriate labels.
) If an offset within a secondary section pair of less than 1 cm cannot be guaranteed for the duration of the complete air
transport, then for transportation you have to notify the relevant authorities and attach appropriate labels.
Original individual packages with secondary section pairs with the Article number 1FN3xxx-
xSxxx-xxxx are correctly stacked in new packaging (bulk packaging). The shipment is not
subject to notification and labeling requirements
A maximum of one additional original individual packaging with one secondary section may
be added to the new (bulk) packaging from example 1. This individual secondary section can
be arbitrarily aligned, a sheet metal case to provide additional shielding is not required. The
shipment of the complete new package is then subject to notification and labeling
requirements.
