Siemens SIMOTICS L-1FN3 Configuration Manual

Assembly drawings/dimension sheets
9.3 1FN3050, 1FN3100, 1FN3150
1FN3 linear motors
518 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Dimensions of the secondary section of 1FN3050
Size
Variable
Unit
1FN3050-4SAxx
Secondary section length
IS
mm
120
Hole pattern (longitudinal)
IS1
mm
60
Total hole pattern (longitudinal)
IS2
mm
lS1 x (2xN2–1)
First hole position of hole pattern (longitudinal)
IS4
mm
31.3
Incline
IS5
mm
5
Width without heatsink profile
bS
mm
58
Hole pattern (transverse)
bS1
mm
44
Width with heatsink profile
bKP1
mm
75
Heatsink profile connector spacing
bKP2
mm
67
Height without heatsink profile with cover
hS1
mm
11.8
Height with heatsink profile with cover
hS2
mm
14.8
Mounting screw clamp length
hS3
mm
9
Screw countersink diameter (outer)
dS1
mm
10
Hole diameter (outer)
dS2
mm
5.5
Hole diameter (inner)
dS3
mm
–
Screw countersink diameter (inner)
dS4
mm
–
Secondary section mounting screws (outside)
MS1
mm
DIN EN ISO 4762 - M5
Secondary section mounting screws (inside)
MS2
mm
–
Dimensions of the secondary section end pieces of 1FN3050
Size
Variable
Unit
1FN3050-0TF00
1FN3050-0TG00
1FN3050-0TJ00
1FN3050-0TC00
Maximum length
lA
mm
42.5
42.5
Hole position (right)
lA1
mm
30
30
Hole distance to secondary section hole
IS3
mm
60
60
Maximum width
bA
mm
79
79
G 1/8 cooler connector position (height) hA1 mm 6 –
Hole pattern (transverse) bA1 mm 44 44
Maximum height (block)
hA
mm
13.8
10.8
