Siemens SIMOTICS L-1FN3 Configuration Manual

Assembly drawings/dimension sheets
9.4 1FN3300, 1FN3450
1FN3 linear motors
536 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Size
Variable
Unit
1FN3300-...
1W
2W
3W
4W
5W
Version with 2 connecting cables (end of the Article No. ...0BA1)
Thread position (height)
hM
mm
23.4
23.4
23.4
23.4
Thread 1 position (width)
bM1
mm
53.5
53.5
53.5
53.5
Thread 2 position (width)
bM2
mm
41.5
41.5
41.5
41.5
Thread 1 diameter GM1 M20x1.5 M20x1.5/
M32x1.5
2)
M20x1.5/
M32x1.5
2)
M20x1.5/
M32x1.5
2)
Thread 2 diameter
GM2
M20x1.5
M20x1.5
M20x1.5
M20x1.5
1)
Valid for motor 1FN3300-3WG00;
2)
valid for motors 1FN3300-2WG00, 1FN3300-3WG00 and 1FN3300-4WC00
