Assembly drawings/dimension sheets
9.4 1FN3300, 1FN3450
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
539
Version with 2 connecting cables (end of the Article No. ...0BA1)
Thread 1 position (width)
Thread 2 position (width)
Thread 1 diameter GM1 M32x1.5/
2)
M32x1.5/
2)
M32x1.5
Valid for motors 1FN3450-3WE00 and 1FN3450-4WE00;
2)
valid for motors 1FN3450-2WA50, 1FN3450-2WC00
