Siemens SIMOTICS L-1FN3 Configuration Manual

Assembly drawings/dimension sheets
9.4 1FN3300, 1FN3450
1FN3 linear motors
542 Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
Dimensions of the secondary section of 1FN3450
Size
Variable
Unit
1FN3450-4SAxx
Secondary section length
IS
mm
184
Hole pattern (longitudinal)
IS1
mm
92
Total hole pattern (longitudinal)
IS2
mm
lS1 x (2xN2–1)
First hole position of hole pattern (longitudinal)
IS4
mm
48.9
Incline
IS5
mm
5
Width without heatsink profile
bS
mm
180
Hole pattern (transverse)
bS1
mm
161
Width with heatsink profile
bKP1
mm
197
Heatsink profile connector spacing
bKP2
mm
189
Height without heatsink profile with cover
hS1
mm
18.5
Height with heatsink profile with cover
hS2
mm
21.5
Mounting screw clamp length
hS3
mm
15
Screw countersink diameter (outer)
dS1
mm
15
Hole diameter (outer)
dS2
mm
9
Hole diameter (inner)
dS3
mm
–
Screw countersink diameter (inner)
dS4
mm
–
Secondary section mounting screws (outside)
MS1
mm
DIN 6912 - M8
Secondary section mounting screws (inside)
MS2
mm
–
Dimensions of the secondary section end pieces of 1FN3300
Size
Variable
Unit
1FN3300-0TF00
1FN3300-0TG00
1FN3300-0TJ00
1FN3300-0TC00
Maximum length
lA
mm
58.5
58.5
Hole position (right)
lA1
mm
30
30
Hole distance to secondary section hole
IS3
mm
92
92
Maximum width
bA
mm
155
155
G 1/8 cooler connector position (height) hA1 mm 6 –
Hole pattern (transverse) bA1 mm 115 115
Maximum height (block)
hA
mm
18.5
15.5
