Siemens SIMOTICS L-1FN3 - Page 55

Description of the motor
2.5 Selection and ordering data
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
53
Article No. Primary section
h
M3
/ h
M1
in mm
b
P
/ b
PK1
in mm
l
P
in mm
l
P,AKT
in mm
m
P
/ m
P,P
in kg
l
S
in mm
m
S
/ m
S,P
in kg
1FN3600-2WB00-0xAx
64.1 / 86
248 / 257
382
322
22.5 / 25
184
4.6 / 5
1FN3600-2WB50-0xAx
64.1 / 86
248 / 257
382
322
22.5 / 25
184
4.6 / 5
1FN3600-2WC00-0xAx
64.1 / 86
248 / 257
382
322
22.5 / 25
184
4.6 / 5
1FN3600-3WB50-0xAx
64.1 / 86
248 / 257
543
483
33.5 / 35.4
184
4.6 / 5
1FN3600-3WB00-0xAx
64.1 / 86
248 / 257
543
483
33.5 / 35.4
184
4.6 / 5
1FN3600-3WC00-0xAx
64.1 / 86
248 / 257
543
483
33.5 / 35.4
184
4.6 / 5
1FN3600-4WA30-0xAx
64.1 / 86
248 / 257
704
644
43 / 45.5
184
4.6 / 5
1FN3600-4WB00-0xAx
64.1 / 86
248 / 257
704
644
43 / 45.5
184
4.6 / 5
1FN3600-4WB50-0xAx
64.1 / 86
248 / 257
704
644
43 / 45.5
184
4.6 / 5
1FN3600-4WC00-0xAx
64.1 / 86
248 / 257
704
644
43 / 45.5
184
4.6 / 5
1FN3600-4WD30-0xAx
64.1 / 86
248 / 257
704
644
43 / 45.5
184
4.6 / 5
1FN3600-5WB00-0xAx
64.1 / 86
248 / 257
0
0
56 / 59.1
184
4.6 / 5
1FN3900-2WB00-0xAx
66.1 / 88
342 / 351
382
322
32.2 / 33.7
184
7.5 / 7.9
1FN3900-2WC00-0xAx
66.1 / 88
342 / 351
382
322
32.2 / 33.7
184
7.5 / 7.9
1FN3900-3WB00-0xAx
66.1 / 88
342 / 351
543
483
47.2 / 49.3
184
7.5 / 7.9
1FN3900-4WA50-0xAx
66.1 / 88
342 / 351
704
644
62.7 / 65.4
184
7.5 / 7.9
1FN3900-4WB00-0xAx
66.1 / 88
342 / 351
704
644
62.7 / 65.4
184
7.5 / 7.9
1FN3900-4WB50-0xAx
66.1 / 88
342 / 351
704
644
62.7 / 65.4
184
7.5 / 7.9
1FN3900-4WC00-0xAx
66.1 / 88
342 / 351
704
644
62.7 / 65.4
184
7.5 / 7.9
h
M3
= motor height without additional heatsinks,
h
M1
= motor height with additional heatsinks,
b
P
=
motor width without
precision cooler, b
PK1
= motor width with precision cooler,
l
P
= length of the primary section (without connection cover),
l
P,AKT
= magnetically active length of the primary section,
m
P
= weight of the primary primary section,
m
P,P
= weight of the
primary section with precision cooler, l
S
= length of the secondary section,
m
S
= weight of the secondary section,
m
S,P
= weight of the secondary section with heatsink profiles
