Siemens SIMOTICS L-1FN3 Configuration Manual

Coupled motors
10.2 Master and stoker
1FN3 linear motors
Configuration Manual, 10/2018, 6SN1197-0AB86-0BP2
579
Table 10- 5 Constant minimum offset between the master and stoker
Primary section type
Same length
Minimum offset M
Peak load motor
1FN3050-xW
72.5 mm
1FN3100-xW
1FN3150-xW
1FN3300-xW 111.2 mm
1FN3450-xW
1FN3600-xW
1FN3900-xW
Continuous load motor
1FN3050-xN
102.5 mm
1FN3100-xN
1FN3150-xN
1FN3300-xN
157.2 mm
1FN3450-xN
1FN3600-xN
1FN3900-xN
Power connection
Table 10- 6 Power connection in a anti-parallel arrangement of two primary sections
Motor Module
Master
Stoker
U2
U
U
V2
V
W
W2
W
V
NOTICE
Phases V and W interchanged
You will find the minimum distance M between the master and the stoker for interchanging
phases V and W in the table in Chapter "Janus arrangement (Page 573)".
If a different minimum distance M is required, you must interchange other phases. Note that
the minimum distance M then changes.
• In this case, contact your local Siemens office or "Technical Support". You will find
contact data in Chapter "Introduction".
