Siemens SINUMERIK 802D sl Programming Manual

Enhanced Level Commands
4.10 Macroprograms
04.07
4-158
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Table 4-10 Address -- variable correspondence and usable addresses for call up
commands (type I), continued
Address in Type I System variableAddress in Type ISystem variable
H $C_H W $C_W
I $C_I[0] X $C_X
J $C_J[0] Y $C_Y
K $C_K[0] Z $C_Z
M $C_M
Correspondence between addresses and system variables (Type II)
To use I, J, and K, they must be specified in the order of I, J, and K.
Since addresses I, J, K c an be programmed up to ten times in a block with macro
call, an array index must be used to access the system variables within the macro
program for these addresses. The syntax for these three system variables is then
$C_I[..], $C_j[..], $C_K[..]. The values are stored in the array in the order program-
med. The number of addresses I, J, K programmed in the block is stored in varia-
bles $C_I_NUM, $C_J_NUM and $C_K_NUM.
Unlike the rest of the system variables, an array index must always be specified for
these three variables. Array index 0 must always be used for cycle calls (e.g. G81);
e.g. N100 R10 = $C_I[0]
Table 4-11 Address -- variable correspondence and usable addresses for call up
commands (type II)
Address -- variable correspondence
Address -- variable correspondence
Address in Type II System variable Address in Type II System variable
A $C_A K5 $C_K[4]
B $C_B I6 $C_I[5]
C $C_C J6 $C_J[5]
I1 $C_I[0] K6 $C_K[5]
J1 $C_J[0] I7 $C_I[6]
K1 $C_K[0] J7 $C_J[6]
I2 $C_I[1] K7 $C_K[6]
J2 $C_J[1] I8 $C_I[7]
K2 $C_K[1] J8 $C_J[7]
I3 $C_I[2] K8 $C_K[7]
J3 $C_J[2] I9 $C_I[8]
K3 $C_K[2] J9 $C_J[8]
I4 $C_I[3] K9 $C_K[8]
J4 $C_J[3] I10 $C_I[9]
K4 $C_K[3] J10 $C_J[9]
