4.10 Macroprograms

04.07

4-159

SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition

Table 4-11 Address -- variable correspondence and usable addresses for call up

commands (type II), continued

Address in Type II System variableAddress in Type IISystem variable

I5 $C_I[4] K10 $C_K[9]

J5 $C_J[4]

Note: If more than one set of I, J, or K is specified, the order of sets is determined for each

I/J/K set, so that variable numbers are determined corresponding to that order.

Example of argument specification

When arguments are specified, the macroprogram call up code must always be

specified before the specification of arguments. If argument specification is given

before the macroprogram call up code, an alarm occurs. The value of argument

specification can include a sign and decimal point independent of the address.

If no decimal point is used, the value is saved to the variable as the value with a

decimal point according to the normal number of digits of that address.

set

sets

G65 P*** A10. C20. X30. Z40. I50. K60. J70. I80.;

$C_I[1]: 80. $C_I_ORDER[1]: 3

§C_J[0]: 70. $C_J_ORDER[0]: 2

$C_K[0]: 60. $C_K_ORDER[0]: 1

$C_I[0]: 50. $C_I_ORDER[0]: 1

$C_Z: 40.

$C_X: 30.

$C_C: 20.

$C_A: 10.

Fig. 4-30 Example of argument specification
