Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-16 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB19
DBX16.7
Active or passive file system
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Passive file system
Signal state 0 or
edge change 1 → 0
Active file system
Application
example(s)
With HMI Advanced always 1
DB19
DBX17.0 - DBX17.7
PLC line offset in the user control file
Edge evaluation: no Signal(s) updated: cyclic
Description This byte for controlling file transfer via the hard disk defines the line of the user control file in which
the control file to be transferred is located.
Application
example(s)
Valid for HMI Advanced, with reference to DB19.DBB13
Dependent on:
DB19.DBX14.7=0 → Act. FS: PLC line offset in a standard control file
DB19.DBX14.7=1 → Pas. FS: PLC line offset in a user control file
DB19
DBX44.0
Mode change disable
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Mode change disable active
Signal state 0 or
edge change 1 → 0
Mode change disable inactive
DB19
DBX45.0
FC9 Out: Active
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX45.1
FC9 Out: Done
Edge evaluation: no Signal(s) updated: cyclic
