5.3 Signals
Mode Group, Channel, Program Operation, Reset Response (K1)
5-10 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB number Byte.Bit Description
21, ... 32.3 Action block active
21, ... 32.4 Approach block active
21, ... 32.5 M00/M01 active
21, ... 32.6 Last action block active
21, ... 33.0 Referencing active
21, ... 33.4 Block search active
21, ... 33.5 M02/M30 active
21, ... 33.6 Transformation active
21, ... 33.7 Program test active
21, ... 35.0 Program status: Running
21, ... 35.1 Program status: Wait
21, ... 35.2 Program status: Stopped
21, ... 35.3 Program status: Interrupted
21, ... 35.4 Program status: Aborted
21, ... 35.5 Channel status: Active
21, ... 35.6 Channel status: Interrupted
21, ... 35.7 Channel status: Reset
21, ... 208 - 271 Number of the active G function of G function group 1 – n (binary)
21, ... 318.0 ASUB is stopped
21, ... 318.1 Block search via program test is active
21, ... 319.0 REPOSMODEEDGEACKN
21, ... 319.1- 319.3 Repos Path Mode Ack: 0 - 2
21, ... 319.5 Repos DEFERRAL Chan
5.3.6 Signals to axis/spindle
DB number Byte.Bit Description
31, ... 10.0 REPOSDELAY
5.3.7 Signals from axis/spindle
DB number Byte.Bit Description
31, ... 70.0 REPOS offset
31, ... 70.1 REPOS offset valid
31, ... 70.2 REPOS Delay Ack
31, ... 72.0 REPOSDELAY
31, ... 76.2 Path axis
