2.16.3 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX62.2 Revolutional feed rate active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
For programming of G95 (revolutional feed rate) in JOG mode or automatic mode.
Corresponding to .... SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feed rate for JOG active)
SD42600 $SC_JOG_FEED_PER_REV_SOURCE
(in the JOG mode revolutional feed rate for geometry axes, on which the frame with rotation acts)
SD43300 $SA_ASSIGN_FEED_PER_REV_SOURCE
(revolutional feed rate for position axes/spindles)
MD32040 $MA_JOG_REV_VELO_RAPID (revolutional feed rate for JOG with rapid traverse
override)
MD32050 $MA_JOG_REV_VELO (revolutional feed rate for JOG mode)
DB31, ...
DBB78 - DBB81 F function for positioning axis
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The F value of a positioning axis programmed in the current block is entered in the axis-specific
PLC interface signal.
The assignment between the DB number and machine axis number is established using the axis
name.
The value is retained until it is overwritten by another.
Format: Binary number in real format.
Application
example(s)
Modification of the programmed F value by the PLC, e.g. by overwriting the selected axis-specific
feed rate override.
Corresponding to .... MD22240 $MC_AUXFU_F_SYNC_TYPE (output time F functions)
