Detailed Description
2.2 Encoder monitoring
Axis Monitoring, Protection Zones (A3)
2-18 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.2.2 Zero mark monitoring
Function
The zero mark monitoring monitors the number of encoder impulses between two encoder
zero marks of the active measuring system. In a properly functioning measuring system, the
number of encoder impulses detected from encoder zero mark to encoder zero mark must
remain the same.
MD36310 $MA_ENC_ZERO_MONITORING (Zero mark monitoring)
Note
The zero mark monitoring is only active below the assigned encoder limit frequency for new
synchronization:
MD36302 $MA_ENC_FREQ_LIMIT_LOW
