No. Parameter
mask
Parameter
internal
Data type Meaning
10 LR <ROP> REAL Thread run-out (inc, to be entered without sign)
11 H1 <TDEP> REAL Thread depth (inc, to be entered without sign)
12 U <FAL> REAL Finishing allowance in X and Z
13 DP <_IANG> REAL Infeed slope as a distance or an angle, see <_AMODE> (ONE MILLION)
αP The infeed slope is applied according to the setting of
parameter <_VARI> (HUNDREDS).
Definition for <_VARI_HUNDREDS = 0 -
Compatibility mode:
> 0 = Side infeed on one side
0 = Infeed vertical in the thread
< 0 = Side infeed with alternating sides
Definition for _VARI_HUNDREDS<>0:
> 0 = Infeed on the positive side
0 = Center infeed
< 0 = Infeed on the negative side
14 α0 <NSP> REAL Starting angle offset for the 1st thread
15 <NRC> INT Number of roughing cuts, see <_VARI> (TEN THOUSANDS)
16 NN <NID> INT Number of non-cuts
17 P0 <_PP1> REAL Pitch for 1st section of thread, see <_PITA>
18 P1 <_PP2> REAL Pitch for 2nd section of thread, see <_PITA>
19 P2 <_PP3> REAL Pitch for 3rd section of thread, see <_PITA>
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1081
