Page #1095 background imageLoading...
Page #1095 background image
No. Parameter
mask
Parameter
internal
Data type Meaning
3 <_ST> INT Status transformations
UNITS:
0 = New, swivel level is deleted and
recalculated using the current pa‐
rameters
1 = Additive, swivel level is added to
active swivel level
TENS: Track tool tip yes/no (only active when
the SWIVEL function is created in the
commissionig)
0 = Do not track tool tip
1 = Track tool tip (TRAORI)
HUNDREDS: Approach/align tool (function is shown in
tool swivel screen form)
0 = Do not approach tool
1 = Approach tool (preferably radial
mill)
2 = Align turning tool (when B axis
kinematic is set up for milling in
commissioning swiveling)
3 = Align milling tool (when B axis
kinematic is set up for milling in
commissioning swiveling)
THOUSANDS: Internal "Swiveling in JOG" parameter
TEN THOUSANDS: See direction parameter <_DIR>
0 = Swivel "Yes"
1 = Swivel "No", "Minus" direction
3)
2 = Swivel "No", "Plus" direction
3)
HUNDRED THOUSANDS: See direction parameter <_DIR>
0 = Compatibility
1 = Direction selection "Minus" opti‐
mized (only for user interface)
4)
2 = Direction selection "Plus" opti‐
mized (only for user interface)
4)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1095
