Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, without sign)
4 Z1 <_DP> REAL Final drilling depth abs/inc (see <_AMODE>UNITS)
5 D <FDEP> REAL 1st drilling depth for the absolute or incremental chip breaking/removal
in relation to the reference point with/without predrilling or in relation to
pilot hole depth (see <_AMODE> TEN THOUSANDS)
6 DF <_DAM> REAL Absolute value / percentage for each additional infeed, degression ab‐
solute value / percentage (see <_AMODE> HUNDRED THOUSANDS)
7 DTB <DTB> REAL Dwell time at each drilling depth (see <_AMODE> TENS)
8 DTS <DTS> REAL Dwell time during chip removal at starting point (see <_AMODE> HUN‐
DREDS)
9 FD1 <FRF> REAL Percentage for the feedrate for the first infeed (see <_AMODE> TEN
MILLION)
10 <VARI> INT
Machining
UNITS: Chip breaking / swarf removal
0 = In one cut
1 = Chip breaking
2 = Swarf removal
3 = Chip breaking and swarf removal
TENS: Retraction during swarf removal
0 = To pilot hole depth
1 = To safety clearance
HUNDREDS: Soft first cut
0 = No
1 = Yes
THOUSANDS: Through drilling
0 = No
1 = Yes
TEN THOUSANDS: Predrilling / pilot hole
0 = Without predrilling
1 = With predrilling
2 = With pilot hole
HUNDRED THOUSANDS: Retraction
0 = To pilot hole depth
1 = To retraction plane
11 V1 <_MDEP> REAL Minimum incremental infeed (only for degression percentage)
12 V2 <_VRT> REAL Retraction distance after each incremental machining step (for chip
breaking only)
0 = Default value 1 mm
> 0 = Variable retraction distance
13 DT <_DTD> REAL Dwell time at final drilling depth (see <_AMODE> THOUSANDS)
Work preparation
3.25 Programming cycles externally
NC programming
1102 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
