No. Parameter
mask
Parameter
internal
Data type Meaning
14 V3 <_DIS1> REAL Incremental limit distance for chip removal only (see <_AMODE> ONE‐
MILLION)
15 FP <S_FP> REAL Feedrate for travel into the pilot hole as value or in % (in conjunction
with <S_AMODE2> HUNDREDS)
16 <S_SDAC2> INT Direction of spindle rotation during approach
3 = M3
4 = M4
5 = M5 (default)
17 SP <S_SV2> REAL Approach with constant spindle speed
(see <S_AMODE2> TEN MILLION)
V4 constant cutting rate
Spindle speed in % of the drilling speed
18 F <S_FB> REAL Drilling feedrate (see <S_AMODE2> UNITS)
19 <_SDAC> REAL Direction of spindle rotation during drilling
3 = M3
4 = M4
20 S <_SV1> REAL Drilling with constant spindle speed
(see <S_AMODE2> ONE MILLION)
V5 constant cutting rate
21 SPOS <S_SPOS> REAL Spindle position, only if approach with M5
22 ZA <S_ZA> REAL Incremental predrilling depth in relation to reference point or absolute
(see <S_AMODE3> UNITS)
23 FA <S_FA> REAL Predrilling feedrate as value or in % (in conjunction with <S_AMODE2>
TENS)
24 ZP <S_ZP> REAL Incremental pilot hole in relation to reference point or absolute or factor
of the hole diameter (see <S_AMODE3> TENS)
25 FS <S_FS> REAL First cut feedrate as value or in % (in conjunction with <S_AMODE2>
THOUSANDS)
26 ZS1 <S_ZS1> REAL Depth of each first cut with constant feedrate (inc)
27 ZS2 <S_ZS2> REAL Depth of each first cut for feedrate increase (inc)
28 N <S_N> INT Number of chip breaking strokes before each chip removal
29 ZD <S_ZD> REAL Incremental remaining drilling depth in relation to final drilling depth or
absolute (see <S_AMODE3> HUNDREDS)
30 FD <S_FD> REAL Remaining drilling feedrate as value or in % (in conjunction
with <S_AMODE2> TEN THOUSANDS)
31 FR <S_FR> REAL Retraction feedrate (in conjunction with <S_AMODE2> HUNDRED
THOUSANDS)
32 <S_SDAC3> INT Direction of spindle rotation during retraction
3 = M3
4 = M4
5 = M5
33 SR <S_SV3> REAL Retraction with constant spindle speed
(see <S_AMODE2> HUNDRED MILLION)
V6 constant cutting rate
Spindle speed in % of the drilling speed
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1103
