Table 3-10 CYCLE994 call parameters
1)
No. Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring variant
Val‐
ues:
UNITS: Inside or outside measurement (default = 1)
1 = Inside measurement
2 = Outside measurement
TENS: Reserved
HUNDREDS: Correction target
0 = Only measurement (no correction of the WO or no tool offset)
1 = Measurement and determination and correction of the WO (see S_KNUM)
3)
2 = Measurement and tool offset (see S_KNUM1)
THOUSANDS: Bypass area
0 = No bypass area
1 = Bypass axis 1st axis of the plane (for G18 Z). Measuring axis, see S_MA.
2 = Bypass axis 2nd axis of the plane (for G18 X). Measuring axis, see S_MA.
3 = Bypass axis 3rd axis of the plane (for G18 Y). Measuring axis, see S_MA.
8)
2 Selection S_KNUM Correction of work offset (WO) or basic WO or basic reference
2)
Val‐
ues:
UNITS:
TENS:
0 = No correction
1 to max. 99 numbers of the work offset or
1 to max. 16 numbers of the basic offset
HUNDREDS: Reserved
THOUSANDS: Correction of WO or basic or basic reference
0 = Correction of the adjustable WO
1 = Correction of the channel-specific basic WO
2 = Correction of the basic reference
3 = Correction of the global basic WO
9 = Correction of the active WO or for G500 in last active channel-specific basic
WO
TEN THOUSANDS: Coarse or fine correction in the WO, basic WO or basic
reference
0 = Fine correction
6)
1 = Coarse correction
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1161
