No. Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
3 Selection S_KNUM1 Correction in tool offset
2), 4)
Val‐
ues:
UNITS:
TENS:
HUNDREDS:
0 = No correction
1 to max. 999 D numbers (cutting edge numbers) for tool offset;
for additive and setup offset, see also S_DLNUM
THOUSANDS: 0 or unique D numbers
TEN THOUSANDS: 0 or unique D numbers
1 to max. 32000, if unique D numbers in MD have been set up
HUNDRED THOUSANDS: Tool offset
2)
0 = No specification (offset tool geometry)
1 = Offset of length L1
2 = Offset of length L2
3 = Offset of length L3
4 = Radius offset
ONE MILLION: Tool offset
2)
0 = No specification (offset of the tool length wear)
1 = Tool offset, additive offset (AO)
5)
Tool offset value is added to the existing AO
2 = Tool offset, setup offset (SO)
5)
SO (new) = SO (old) + AO (old) offset value, AO (new) = 0
3 = Tool offset, setup offset (SO)
5)
Tool offset value is added to the existing SO
4 = Tool offset, geometry
TEN MILLION: Tool offset
2)
0 = No specification (offset in tool geometry normal, not inverted)
1 = Offset inverted
HUNDRED MILLIONS: Tool offset
0 = Tool offset without replacement tools
1 = Tool offset in replacement tool (_DP)
4 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(default=1)
5 X0 S_SETV Setpoint
6 X S_MA Number of the measuring axis (default=1)
Val‐
ues:
1 = 1st axis of the plane (for G18 Z)
2 = 2nd axis of the plane (for G18 X)
3 = 3rd axis of the plane (for G18 Y)
8)
7 X1 S_SZA Bypass distance in the measured axis
8 Y1 S_SZO Bypass distance in the bypass axis
9 DFA S_FA Measurement path
10 TSA S_TSA Safe area
11 Measure‐
ments
S_NMSP Number of measurements at the same location
2)
(default=1)
12 T S_TNAME Tool name
2)
Work preparation
3.25 Programming cycles externally
NC programming
1162 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
