Table 3-13 CYCLE998 call parameters
1)
No
.
Screen form
parameter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring variant (default=5)
Val‐
ues:
UNITS: Contour element
5 = Measure edge (one angle)
6 = Measure plane (two angles)
TENS: Reserved
HUNDREDS: Correction target
0 = Only measurement and no correction of WO
1 = Measurement and determination and correction of the WO (see S_KNUM)
THOUSANDS: Protection zone
0 = No consideration of a protection zone
1 = Consideration of a protection zone
TEN THOUSANDS: Measurement with spindle reversal (difference measurement)
0 = Measurement without spindle reversal
1 = Measurement with spindle reversal
HUNDRED THOUSANDS: Measurement at an angle or paraxial
0 = Measurement at an angle
1 = Measurement paraxial
2 Selection S_KNUM Correction of work offset (WO) or basic WO or basic reference
2)
Val‐
ues:
UNITS:
TENS:
0 = No correction
1 to max. 99 numbers of the work offset or
1 to max. 16 numbers of the basic offset
HUNDREDS: Reserved
THOUSANDS: Correction of WO or basic or basic reference
0 = Correction of the adjustable WO
1 = Correction of the channel-specific basic WO
2 = Correction of the basic reference
9 = Correction of the active WO or for G500 in last active channel-specific basic WO
TEN THOUSANDS: Coarse or fine correction in the WO or basic WO or basic
reference
3)
0 = Fine correction
1 = Coarse correction
3
A, B, C
S_RA Offset target coordinate rotation or rotary axis
14)
Val‐
ues:
0 = Correction target coordinate rotation around the axis that results from param‐
eter S_MA
4)
>0 = Correction target rotary axis. Number of the channel axis number of the rotary
axis (preferably rotary table). The angular offset is made in the translatory part of
the WO of the rotary axis.
4 Icon+
number
S_PRNUM Number of the field of the probe parameter
(default=1)
5 DX / DY / DZ S_SETV Distance (incremental) from the starting position to measuring point P1 of the measuring axis
(S_MA)
5)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1169
