Table 3-17 CYCLE997 call parameters
1), 2)
No
.
Screen
form pa‐
rameter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring variant (default =9)
Val‐
ues:
UNITS: Contour element
9 = Measure ball
TENS: Repeat measurement
0 = Without measurement repetition
1 = With measurement repetition
HUNDREDS: Correction target
0 = Only measurement (no correction of WO)
1 = Measurement and determination and correction of the WO (see S_KNUM)
THOUSANDS: Measuring strategy
0 = Paraxial measurement, without starting angle, probe alignment corresponding
to SD55740, bit 1
1 = Circling measurement, with starting angle, probe alignment corresponding to
SD55740, Bit 1
2 = Circling measurement, with starting angle, align probe in the switching direction
3 = Paraxial measurement, with starting angle, probe alignment corresponding to
SD55740, bit 1
4 = Paraxial measurement, with starting angle, align probe in the switching direction
TEN THOUSANDS: Number of balls to be measured
0 = Measure one ball
1 = Measure three balls
HUNDRED THOUSANDS: Number of measuring points, only for measurement at
an angle (note measuring strategy: THOUSANDS position > 0)
0 = Three measuring points for measurement at an angle (traversing around the
ball)
1 = Four measuring points for measurement at an angle (traversing around the ball)
ONE MILLION: Determination of the diameter setpoint of the ball
0 = No determination of the diameter setpoint of the ball
1 = Determination of the diameter setpoint of the ball
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1181
