Table 3-19 CYCLE996 call parameters
1)
No
.
Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measurement version (default=1)
Val‐
ues:
UNITS: Measuring sequence
0 = Calculate kinematics (selection with: Result display, protocol, change of the
swivel data sets, where relevant with operator acknowledgment), see _AMODE
1 = 1st measurement
2 = 2nd measurement
3 = 3rd measurement
TENS: Reserved
0 = 0
HUNDREDS: Measurement version for 1st to 3rd measurement
0 = Measurement of the calibration ball paraxial
1 = Measurement of the calibration ball at an angle and no spindle correction
3)
2 = Measurement of the calibration ball and correction of the spindle in the switch‐
ing direction of the probe
3)
3 = Paraxial measurement, with starting angle
8)
4 = Paraxial measurement, with starting angle, tracking spindle in the switching
direction of the probe
8)
THOUSANDS: Calculate correction target for kinematics
4)
0 = Measuring only. Swivel data sets are calculated, but remain unchanged
1 = calculate swivel data set. Swivel data sets are, if necessary, changed after
acknowledgment by the operator
4)
TEN THOUSANDS: Measuring axis (rotary axis 1 or 2) or vector chain open or
closed for calculate kinematics
0 = Vector chain closed (only for calculate kinematics)
1 = Rotary axis 1 (only for 1st to 3rd measurement)
2 = Rotary axis 2 (only for the 1st to 3rd measurement)
5)
3 = Vector chain open (only for calculate kinematics)
HUNDRED THOUSANDS: Normalizing of rotary axis 1 for calculate kinematics
0 = No scaling rotary axis 1
1 = Scaling in the direction of the 1st axis of the plane (for G17 X)
2 = Scaling in the direction of the 2nd axis of the plane (for G17 Y)
3 = Scaling in the direction of the 3rd axis of the plane (for G17 Z)
ONE MILLION: Normalizing of rotary axis 2 for calculate kinematics
5)
0 = No scaling rotary axis 2
1 = Scaling in the direction of the 1st axis of the plane (for G17 X)
2 = Scaling in the direction of the 2nd axis of the plane (for G17 Y)
3 = Scaling in the direction of the 3rd axis of the plane (for G17 Z)
TEN MILLION: Log file
0 = No protocol file
1 = Protocol file with the calculated vectors (tool carrier) and the 1st dynamic 5-axis
transformation (TRAORI(1)), if set-up in MDs.
2 S_TC Number of the swivel data record (tool carrier)
3 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(default=1)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1185
