Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
A7 A Tool orientation: 1st vector component for in‐
termediate orientation on peripheral surface
of taper
s +/- PM-NC
ABS F Absolute value (amount) +/- +/- PM-NC
AC K Absolute dimensions of coordinates/positions s +/- PM-NC
ACC K Effect of current axial acceleration m +/- +/- PM-NC
ACCLIMA K Effect of current maximum axial acceleration m +/- +/- PM-NC
ACN K Absolute dimensions for rotary axes, ap‐
proach position in negative direction
s +/- PM-NC
ACOS F Arc cosine
(trigon. function)
+/- +/- PM-NC
ACP K Absolute dimensions for rotary axes, ap‐
proach position in positive direction
s +/- PM-NC
ACTBLOCNO P Output of current block number of an alarm
block, even if "current block display sup‐
pressed" (DISPLOF) is active!
+/- PM-NC
ADDFRAME F Inclusion and possible activation of a meas‐
ured frame
+/- - PM-NC, FM-B
ADIS A Rounding clearance for path functions G1,
G2, G3, ...
m +/- PM-NC
ADISPOS A Rounding clearance for rapid traverse G0 m +/- PM-NC
ADISPOSA P Size of the tolerance window for IPOBRKA m +/- +/- PM-NC
ALF A Rapid lift angle m +/- PM-NC
AMIRROR G Programmable mirroring s +/- PM-NC
AND K Logical AND +/- PM-NC
ANG A Contour angle s +/- PM-NC
AP A Polar angle m/s +/- PM-NC
APR K Read/show access protection +/- PM-NC
APRB K Read access right, OPI +/- PM-NC
APRP K Read access right, part program +/- PM-NC
APW K Write access protection +/- PM-NC
APWB K Write access right, OPI +/- PM-NC
APWP K Write access right, part program +/- PM-NC
APX K Definition of the access right for executing the
specified language element
+/- PM-NC
AR A Opening angle m/s +/- PM-NC
AROT G Programmable rotation s +/- PM-NC
AROTS G Programmable frame rotations with solid an‐
gles
s +/- PM-NC
AS K Macro definition +/- PM-NC
ASCALE G Programmable scaling s +/- PM-NC
ASIN F Arithmetic function, arc sine +/- +/- PM-NC
ASPLINE G Akima spline m +/- PM-NC
Tables
4.1 Operations
NC programming
1198 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
