Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
ATAN2 F Arc tangent 2 +/- +/- PM-NC
ATOL A Axis-specific tolerance for compressor func‐
tions, orientation smoothing and smoothing
types
m +/- PM-NC
ATRANS G Additive programmable work offset s +/- PM-NC
AUXFUDEL P Delete auxiliary function channel-specifically
from the global list
+/- - FM-B
AUXFUDELG P Delete all auxiliary functions of an auxiliary
function group channel-specifically from the
global list
+/- - FM-B
AUXFUMSEQ P Determine output sequence of M auxiliary
functions
+/- - FM-B
AUXFUSYNC P Generate a complete part program block for
the channel-specific SERUPRO end ASUB as
string from the global list of auxiliary functions
+/- - FM-B
AX K Variable axis identifier m/s +/- PM-NC
AXCTSWE P Rotate axis container +/- - PM-NC
AXCTSWEC P Cancel enable for axis container rotation +/- +/- PM-NC
AXCTSWED P Rotating axis container (command variant for
commissioning!)
+/- - PM-NC
AXIS K Axis identifier, axis address +/- PM-NC
AXNAME F Converts input string into axis identifier +/- - PM-NC
AXSTRING F Converts string spindle number +/- - PM-NC
AXTOCHAN P Request axis for a specific channel. Possible
from NC program and synchronous action.
+/- +/- PM-NC
AXTOSPI F Converts axis identifier into a spindle index +/- - PM-NC
B A Axis name m/s +/- PM-NC
B2 A Tool orientation: RPY or Euler angle s +/- PM-NC
B3 A Tool orientation: component of the direction
vector
s +/- PM-NC
B4 A Tool orientation: 2nd component of the sur‐
face normal vector at start of block
s +/- PM-NC
B5 A Tool orientation: 2nd component of the sur‐
face normal vector at end of block
s +/- PM-NC
B6 A Tool orientation: 2nd component of the direc‐
tion vector for taper's axis of rotation
s +/- PM-NC
B7 A Tool orientation: 2nd vector component for in‐
termediate orientation on peripheral surface
of taper
s +/- PM-NC
B_AND O Bit-by-bit AND +/- PM-NC
B_OR O Bit-by-bit OR +/- PM-NC
B_NOT O Bit-by-bit negation +/- PM-NC
B_XOR O Bit-by-bit exclusive OR +/- PM-NC
BAUTO G Definition of the first spline section by means
of the next 3 points
m +/- PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1199
