Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CYCLE978 C (M) Measure the position of an edge in the work‐
piece coordinate system
+/- PM-MC
CYCLE979 C (M) Determine center in the plane, measure radi‐
us of circle segment.
+/- PM-MC
CYCLE982 C (M) Calibrate tool probe, measure turning drilling
and milling tools (only for turning)
+/- PM-MC
CYCLE994 C (M) Determine the workpiece zero in the selected
measuring axis with 2-point measurement (on‐
ly for turning).
+/- PM-MC
CYCLE995 C (M) Measure the angularity of the spindle on a ma‐
chine tool
+/- PM-MC
CYCLE996 C (M) Determine transformation-relevant data for
kinematic transformations with rotary axes
+/- PM-MC
CYCLE997 C (M) Determine center and diameter of a ball,
measure center of three distributed balls
+/- PM-MC
CYCLE998 C (M) Determine the angular position of a surface
(plane) referred to the working plane, deter‐
mine angle of edges in the workpiece coordi‐
nate system.
+/- PM-MC
CYCLE4071 C (T) Longitudinal grinding with infeed at the rever‐
sal point
+/- PM-NC
CYCLE4072 C (T) Longitudinal grinding with infeed at the rever‐
sal point and cancel signal
+/- PM-NC
CYCLE4073 C (T) Longitudinal grinding with continuous infeed +/- PM-NC
CYCLE4074 C (T) Longitudinal grinding with continuous infeed
and cancel signal
+/- PM-NC
CYCLE4075 C (T) Surface grinding with infeed at the reversal
point
+/- PM-NC
CYCLE4077 C (T) Surface grinding with infeed at the reversal
point and cancel signal
+/- PM-NC
CYCLE4078 C (T) Surface grinding with continuous infeed +/- PM-NC
CYCLE4079 C (T) Surface grinding with intermittent infeed +/- PM-NC
CYCLE9960 C (M) Measure kinematics completely +/- PM-MC
Operations D ... F
Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1)2)3)4)5)
for explanations, see legend (Page 1197).
D A Tool offset number + PM-NC
D0 A With D0, offsets for the tool are ineffective + PM-NC
DAC K Absolute non-modal axis-specific diameter
programming
s + PM-NC
DC K Absolute dimensions for rotary axes, ap‐
proach position directly
s + PM-NC
Tables
4.1 Operations
NC programming
1208 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
