Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CYCLE119 C (M) Determining position in space +/- PM-MC
CYCLE150 C (M) Displaying/logging measurement results +/- PM-MC
CYCLE435 C (T) Calculate dressing tool position +/- PM-NC
CYCLE495 C (T) Form-truing +/- PM-NC
CYCLE750 C (A) Internal operating cycle for CYCLE751 ... CY‐
CLE759 (contains the MMC command for the
actual function call)
- FM-A
CYCLE751 C (A) Open / perform / close an optimization session M FM-A
CYCLE752 C (A) Add axis to an optimization session M FM-A
CYCLE753 C (A) Select optimization mode M FM-A
CYCLE754 C (A) Add / remove language block M FM-A
CYCLE755 C (A) Backing up/restoring data block M FM-A
CYCLE756 C (A) Activate optimization results M FM-A
CYCLE757 C (A) Store optimization data M FM-A
CYCLE758 C (A) Changing the parameter value M FM-A
CYCLE759 C (A) Read parameter value M FM-A
CYCLE782 C (T) Adapt to load +/- PM-NC
CYCLE800 C (T) Swiveling +/- PM-NC
CYCLE801 C (T) Grid or frame +/- PM-NC
CYCLE802 C (T) Arbitrary positions +/- PM-NC
CYCLE830 C (T) Deep-hole drilling 2 +/- PM-NC
CYCLE832 C (T) High-Speed Settings +/- PM-NC
CYCLE840 C (T) Tapping with compensating chuck +/- PM-NC
CYCLE899 C (T) Open slot milling +/- PM-NC
CYCLE930 C (T) Groove +/- PM-NC
CYCLE940 C (T) Undercut forms +/- PM-NC
CYCLE951 C (T) Stock removal +/- PM-NC
CYCLE952 C (T) Contour grooving +/- PM-NC
CYCLE961 C (M) Determine the position of a workpiece corner
(inner or outer) and insert as work offset.
+/- PM-MC
CYCLE971 C (M) Calibrate tool probe, measure tool length and/
or tool radius (only for milling)
+/- PM-MC
CYCLE973 C (M)
Calibrate a workpiece probe on a surface on
the workpiece or in a groove (only for turning)
+/- PM-MC
CYCLE974 C (M) Determine the workpiece zero in the selected
measuring axis, determine tool offset with 1-
point measurement (only for turning).
+/- PM-MC
CYCLE976 C (M) Calibrate a workpiece probe in a calibration
ring or on a calibration ball completely in the
working plane or at an edge for a particular
axis and direction
+/- PM-MC
CYCLE977 C (M) Determine the center in the plane as well as
the width or the diameter
+/- PM-MC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1207
