Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
CUT3DCD G 3D TRC in relation to a differential tool for cir‐
cumferential milling
m +/- PM-NC
CUT3DF G 3D TRC for face milling with change in orien‐
tation
m +/- PM-NC
CUT3DFD G 3D TRC in relation to a differential tool for face
milling with change in orientation
m +/- PM-NC
CUT3DFF G 3D TRC for face milling with constant orienta‐
tion. The tool orientation is the direction de‐
fined by G17 - G19 and, in some cases, rota‐
ted by a frame.
m +/- PM-NC
CUT3DFS G 3D TRC for face milling with constant orienta‐
tion. The tool orientation is defined by G17 -
G19 and is not influenced by frames.
m +/- PM-NC
CUTCONOF
6)
G Deactivate tool radius compensation m +/- PM-NC
CUTCONON G Activate tool radius compensation m +/- PM-NC
CUTMOD A Activate Modification of the offset data for ro‐
tatable tools (in connection with orientable tool
carriers)
m +/- PM-NC
CUTMODK A Activate Modification of the offset data for ro‐
tatable tools (in connection with orientation
transformations defined by kinematic chains)
m +/- PM-NC
CYCLE60 C (T) Engraving cycle +/- PM-NC
CYCLE61 C (T) Face milling +/- PM-NC
CYCLE62 C (T) Contour call +/- PM-NC
CYCLE63 C (T) Contour pocket milling +/- PM-NC
CYCLE64 C (T) Contour pocket predrilling +/- PM-NC
CYCLE70 C (T) Thread milling +/- PM-NC
CYCLE72 C (T) Path milling +/- PM-NC
CYCLE76 C (T) Milling the rectangular spigot +/- PM-NC
CYCLE77 C (T) Circular spigot milling +/- PM-NC
CYCLE78 C (T) Mill cutting thread +/- PM-NC
CYCLE79 C (T) Multiple edge +/- PM-NC
CYCLE81 C (T) Drilling, centering +/- PM-NC
CYCLE82 C (T) Drilling, counterboring +/- PM-NC
CYCLE83 C (T) Deep-hole drilling +/- PM-NC
CYCLE84 C (T) Tapping without compensating chuck +/- PM-NC
CYCLE85 C (T) Reaming +/- PM-NC
CYCLE86 C (T) Boring +/- PM-NC
CYCLE92 C (T) Parting +/- PM-NC
CYCLE95 C (T) Stock removal along the contour +/- PM-NC
CYCLE98 C (T) Thread chain +/- PM-NC
CYCLE99 C (T) Thread cutting +/- PM-NC
CYCLE116 C (M) Calculation of center point and radius of a cir‐
cle
+/- PM-MC
Tables
4.1 Operations
NC programming
1206 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
