Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1)2)3)4)5)
for explanations, see legend (Page 1197).
EGON P Turn on electronic gear + - PM-NC
EGONSYN P Turn on electronic gear + - PM-NC
EGONSYNE P Turn on electronic gear, with specification of
approach mode
+ - PM-NC
ELSE K NC program: Program branch if the IF condi‐
tion is not fulfilled.
+ - PM-NC
ELSE K Synchronous action: Triggering of actions
when condition unfulfilled
- + FM-SA
ENABLE P Interrupt ON + - PM-NC
ENAT
6)
G Natural transition to next traversing block m + PM-NC
ENDFOR K End line of FOR counter loop + PM-NC
ENDIF K End line of IF branch + PM-NC
ENDLABEL K End label for part program repetitions with RE‐
PEAT
+ PM-NC, FM-B
ENDLOOP K End line of endless program loop LOOP + PM-NC
ENDPROC K End line of program with start line PROC +
ENDWHILE K End line of WHILE loop + PM-NC
ESRR P Parameterizing drive-autonomous ESR re‐
traction in the drive
+ PM-NC
ESRS P Parameterizing drive-autonomous ESR shut‐
down in the drive
+ PM-NC
ETAN G Tangential transition to next traversing block
at spline begin
m + PM-NC
EVERY K Execute synchronous action on transition of
condition from FALSE to TRUE
- + FM-SA
EX K Keyword for value assignment in exponential
notation
+ PM-NC
EXECSTRING P Transfer of a string variable with the executing
part program line
+ - PM-NC
EXECTAB P Execute an element from a motion table + - PM-NC
EXECUTE P Program execution ON + - PM-NC
EXP F Exponential function ex + + PM-NC
EXTCALL A Execute external subprogram + + PM-NC
EXTCLOSE P Closing external device / file that was opened
for writing
+ - PM-NC
EXTERN K Declaration of a subprogram with parameter
transfer
+ PM-NC
EXTOPEN P Opening external device / file for the channel
for writing
+ - PM-NC
F A Feedrate value
(in conjunction with G4 the dwell time is also
programmed with F)
+ + PM-NC
FA K Axial feedrate m + + PM-NC
FAD A Infeed rate for soft approach and retraction + PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1211
