Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
SETPIECE P Set piece number for all tools assigned to the
spindle
+/- - FM-TM
SETTA P Activate tool from wear group +/- - FM-TM
SETTCOR F Modification of tool components taking all sup‐
plementary conditions into account
+/- - PM-NC
SETTIA P Deactivate tool from wear group +/- - FM-TM
SF A Starting point offset for thread cutting m +/- PM-NC
SIN F Sine (trigon. function) +/- +/- PM-NC
SIRELAY F Activate the safety functions parameterized
with SIRELIN, SIRELOUT, and SIRELTIME
- +/- FM-SI
SIRELIN P Initialize input variables of function block +/- - FM-SI
SIRELOUT P Initialize output variables of function block +/- - FM-SI
SIRELTIME P Initialize timers of function block +/- - FM-SI
SLOT1 C (T) Longitudinal groove +/- PM-NC
SLOT2 C (T) Circumferential groove +/- PM-NC
SOFT G Soft path acceleration m +/- PM-NC
SOFTA P Activate jerk-limited axis acceleration for the
programmed axes
+/- - PM-NC
SON G Nibbling ON m +/- PM-NC
SONS G Nibbling ON in interpolation cycle m +/- PM-NC
SPATH
6)
G Path reference for FGROUP axes is arc length m +/- PM-NC
SPCOF P Switch master spindle or spindle(s) from posi‐
tion control to speed control
m +/- - PM-NC
SPCON P Switch master spindle or spindle(s) from
speed control to position control
m +/- - PM-NC
SPI F Converts spindle number into axis identifier +/- - PM-NC
SPIF1
6)
G Fast
NC inputs/outputs for punching/nibbling byte 1
m +/- FM-TE
SPIF2 G Fast
NC inputs/outputs for punching/nibbling byte 2
m +/- FM-TE
SPLINEPATH P Define spline grouping +/- - PM-NC
SPN A Number of path sections per block s +/- PM-NC
SPOF
6)
G Stroke OFF,
nibbling, punching OFF
m +/- PM-NC
SPOS K Spindle position m +/- +/- PM-NC
SPOSA K Spindle position across block boundaries m +/- PM-NC
SPP A Length of a path section m +/- PM-NC
SPRINT F Returns an input string formatted +/- PM-NC
SQRT F Square root
(arithmetic function)
+/- +/- PM-NC
SR A Oscillation retraction path for synchronous ac‐
tion
s +/- PM-NC
SRA K Oscillation retraction path with external input
axial for synchronous action
m +/- PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1227
