Curve table functions
Identifier Return
value
Parameter Explanation
1. 2. 3. 4. 5. 6.
CTABISLOCK INT:
Lock
state
INT:
Table
number
Determines the lock
state of the curve table:
> 0: Table is locked
1: CTABLOCK
2: Active coupling
3: CTABLOCK and ac‐
tive coupling
0: Table is not locked
-1: Table does not ex‐
ist
CTABEXISTS INT:
Exis‐
tence
INT:
Table
number
Determines the exis‐
tence of the curve ta‐
ble in the static or dy‐
namic NC memory:
0: FALSE
1: TRUE
CTABMEMTYP INT:
Storage
location
INT:
Table
number
Determines the stor‐
age location of the
curve table:
1: DRAM
0: SRAM
-1: Table does not ex‐
ist
CTABPERIOD INT:
Periodici‐
ty
INT:
Table
number
Determines the perio‐
dicity of the curve ta‐
ble:
0: Not periodic
1: Periodic in leading
axis
2: Periodic in leading
and following axis
-1: Table does not ex‐
ist
CTABNO INT:
Number
of curve
tables
Determines the num‐
ber of defined curve ta‐
bles (in static and dy‐
namic NC memory)
CTABNOMEM INT:
Number
of curve
tables
STRING:
Storage
location:
"SRAM",
"DRAM"
Determines the num‐
ber of defined curve ta‐
bles in the specified
memory
CTABFNO INT:
Number
of tables
STRING:
Storage
location:
"SRAM",
"DRAM"
Determines the num‐
ber of curve tables still
possible in the speci‐
fied memory
Tables
4.6 Predefined functions
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1293
