Curve table functions
Identifier Return
value
Parameter Explanation
1. 2. 3. 4. 5. 6.
CTABSEG INT:
Number
of curve
seg‐
ments
STRING:
Storage
location:
"SRAM",
"DRAM"
STRING:
Segment
type:
"L": Line‐
ar
"P": Poly‐
nomial
Determines the num‐
ber of curve segments
used of the specified
segment type in the
specified memory
>=0: Number
-1: Invalid memory
type
If parameter 2 is not
programmed, the sum
of the linear and poly‐
nomial segments is
output.
CTABFSEG INT:
Number
of curve
seg‐
ments
STRING:
Storage
location:
"SRAM",
"DRAM"
STRING:
Segment
type:
"L": Line‐
ar
"P": Poly‐
nomial
Determines the num‐
ber of still possible
curve segments of the
specified segment
type in the specified
memory
>=0: Number
-1: Invalid memory
type
CTABSEGID INT:
Number
of curve
seg‐
ments
INT:
Table
number
STRING:
Segment
type:
"L": Line‐
ar
"P": Poly‐
nomial
Determines the num‐
ber of curve segments
of the specified seg‐
ment type that are
used by the curve table
>=0: Number
-1: Table does not ex‐
ist
CTABMSEG INT:
Number
of curve
seg‐
ments
STRING:
Storage
location:
"SRAM",
"DRAM"
STRING:
Segment
type:
"L": Line‐
ar
"P": Poly‐
nomial
Determines the maxi‐
mum possible number
of curve segments of
the specified segment
type in the specified
memory
>=0: Number
-1: Table does not exist
CTABPOL INT:
Number
of curve
polyno‐
mials
STRING:
Storage
location:
"SRAM",
"DRAM"
Determines the num‐
ber of used curve poly‐
nomials in the speci‐
fied memory
>=0: Number
-1: Table does not exist
Tables
4.6 Predefined functions
NC programming
1294 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
