Curve table functions
Identifier Return
value
Parameter Explanation
1. 2. 3. 4. 5. 6.
CTABPOLID INT:
Number
of curve
polyno‐
mials
INT:
Table
number
Determines the num‐
ber of curve polyno‐
mials used by the
curve table
>=0: Number
-1: Table does not exist
CTABFPOL INT:
Number
of curve
polyno‐
mials
STRING:
Storage
location:
"SRAM",
"DRAM"
Determines the maxi‐
mum possible number
of curve polynomials in
the specified memory:
>=0: Number
-1: Table does not exist
CTABMPOL INT:
Number
of curve
polyno‐
mials
STRING:
Storage
location:
"SRAM",
"DRAM"
Determines the maxi‐
mum possible number
of curve polynomials in
the specified memory:
>=0: Number
-1: Table does not exist
CTABSSV REAL:
Follow‐
ing axis
position
REAL:
Leading
axis posi‐
tion
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult
AXIS:
Follow‐
ing axis
for scal‐
ing
AXIS:
Leading
axis for
scaling
Determines the follow‐
ing axis position at the
start of the curve seg‐
ment belonging to the
specified leading axis
value
CTABSEV REAL:
Follow‐
ing axis
position
REAL:
Leading
axis posi‐
tion
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult
AXIS:
Follow‐
ing axis
for scal‐
ing
AXIS:
Leading
axis for
scaling
Determines the follow‐
ing axis position at the
end of the curve seg‐
ment belonging to the
specified leading axis
value
CTABTSV REAL:
Follow‐
ing axis
position
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult at
start of
the table
AXIS:
Follow‐
ing axis
Determines the follow‐
ing axis position at the
start of the curve table.
CTABTEV REAL:
Follow‐
ing axis
position
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult at
end of
the table
AXIS:
Follow‐
ing axis
Determines the follow‐
ing axis position at the
end of the curve table.
CTABTSP REAL:
Leading
axis posi‐
tion
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult at
start of
the table
AXIS:
Leading
axis
Determines the lead‐
ing axis position at the
start of the curve table.
Tables
4.6 Predefined functions
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1295
