Siemens SINUMERIK ONE MCP 2400.4c Programming Manual

Curve table functions
Identifier Return
value
Parameter Explanation
1. 2. 3. 4. 5. 6.
CTABTEP REAL:
Leading
axis posi‐
tion
INT:
Table
number
VAR RE‐
AL[ ]:
Pitch re‐
sult at
end of
the table
AXIS:
Leading
axis
Determines the lead‐
ing axis position at the
end of the curve table.
CTABTMIN REAL:
Minimum
value
INT:
Table
number
REAL:
Leading
value in‐
terval
lower lim‐
it
REAL:
Leading
value in‐
terval up‐
per limit
AXIS:
Follow‐
ing axis
AXIS:
Leading
axis
Determines the mini‐
mum value of the fol‐
lowing axis in the en‐
tire definition range of
the curve table or in a
defined interval
CTABTMAX REAL:
Maxi‐
mum val‐
ue
INT:
Table
number
REAL:
Leading
value in‐
terval
lower lim‐
it
REAL:
Leading
value in‐
terval up‐
per limit
AXIS:
Follow‐
ing axis
AXIS:
Leading
axis
Determines the maxi‐
mum value of the fol‐
lowing axis in the en‐
tire definition range of
the curve table or in a
defined interval
Note:
The curve table functions can also be programmed in synchronized actions.
Axis functions
Identifier Return value Parameter
1. 2. 3. 4. Explanation
AXNAME AXIS:
Axis identifier
STRING [ ]:
Input string
Converts input string in‐
to axis identifier
AXSTRING STRING[ ]:
Axis name
AXIS:
Axis identifier
Converts axis identifier
into string
ISAXIS BOOL:
Axis present
(TRUE) or not
(FALSE)
INT:
Number of the
geometry axis
(1 to 3)
Checks whether the ge‐
ometry axes 1 to 3
specified as parame‐
ters are present in ac‐
cordance with machine
data MD20050
$MC_AXCONF_GEO‐
AX_ASSIGN_TAB
SPI AXIS:
Axis identifier
INT:
Spindle num‐
ber
Converts spindle num‐
ber into axis identifier
AXTOSPI INT:
Spindle num‐
ber
AXIS:
Axis identifier
Converts axis identifier
into spindle number
Tables
4.6 Predefined functions
NC programming
1296 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
