Other functions
Identifier Return
value
Parameter Explanation
1. 2. 3. 4. 5. 6.
PROTD REAL:
Clear‐
ance of
the two
protec‐
tion
zones
STRING:
Name of
the 1st
protec‐
tion area
STRING:
Name of
the 2nd
protec‐
tion area
VAR RE‐
AL:
Return
value:
3-dimen‐
sional
clear‐
ance vec‐
tor
BOOL:
Measur‐
ing sys‐
tem for
clear‐
ance and
clear‐
ance vec‐
tor (op‐
tional)
Determines the clear‐
ance of the two speci‐
fied protection areas.
DELOBJ INT:
Error
number
STRING:
Compo‐
nent type
to be de‐
leted
INT:
Start in‐
dex of
the com‐
ponents
to be de‐
leted (op‐
tional)
INT:
End in‐
dex of
the com‐
ponents
to be de‐
leted (op‐
tional)
BOOL:
Alarm
suppres‐
sion
(optional)
Deletes elements from
kinematic chains, pro‐
tection areas, protec‐
tion area elements, col‐
lision pairs and transfor‐
mation data
NAMETOINT INT:
System
variable
index
STRING:
Name of
the sys‐
tem vari‐
able ar‐
ray
STRING:
Charac‐
ter
string /
name
BOOL:
Alarm
suppres‐
sion
(optional)
Determines the associ‐
ated system variable in‐
dex based on the char‐
acter string
ORISOLH INT:
Error
number
INT:
Controls
the be‐
havior of
the func‐
tion
REAL:
First an‐
gle
REAL:
Second
angle
Helps the user to set
the rotary axis positions
of a machine so that a
turning tool can be
brought into a defined,
kinematic-independent
position relative to the
workpiece.
Requirement:
A 6-axis transformation
is active that has been
parameterized with kin‐
ematic chains.
CORRTRAFO INT:
Error
number
REAL:
Correc‐
tion vec‐
tor
INT:
Element
to be
modified
INT:
Correc‐
tion
mode
BOOL:
Alarm
suppres‐
sion
(optional)
Modifies offset vectors
or direction vectors of
the orientation axes in
the kinematic model of
the machine.
CORRTC INT:
Error
number
REAL:
Correc‐
tion vec‐
tor
INT:
Element
to be
modified
INT:
Correc‐
tion
mode
BOOL:
Alarm
suppres‐
sion
(optional)
Modify offset vectors or
direction vectors of ori‐
entable tool carriers ac‐
cording to machine
measurement.
Tables
4.6 Predefined functions
NC programming
1302 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
