Program code Comment
N160 SETMS ; Switching back to master spindle S1.
Further information
Interpretation of the S value for the master spindle
If function G331 or G332 is active in G group 1 (modally valid motion commands), the
programmed S-value will always be interpreted as the speed in rpm. Otherwise, the
interpretation of the S-value will depend upon G group 15 (feedrate type): If G96, G961 or G962
is active, the S-value is interpreted as a constant cutting rate in m/min; otherwise, it is
interpreted as a speed in rpm.
Changing from G96/G961/G962 to G331/G332 sets the value of the constant cutting rate to
zero; changing from G331/G332 to a function within the G group 1 other than G331/G332 sets
the speed value to zero. The corresponding S-values have to be reprogrammed if required.
Preset M commands M3, M4, M5
In a block with axis commands, functions M3, M4, M5 are activated before the axis movements
commence (basic setting on the control).
Example:
Program code Comment
N10 G1 F500 X70 Y20 S270 M3 ; The spindle ramps up to 270 rpm and the move-
ments then executed in X and Y.
N100 G0 Z150 M5 ; Spindle stop before the retraction movement
in Z.
Note
Machine data can be used to set when axis movements should be executed; either once the
spindle has powered up to the setpoint speed, or immediately after the programmed switching
operations have been traversed.
Working with multiple spindles
Five spindles (master spindle plus four additional spindles) can be available in one channel at
the same time.
One of the spindles is defined in machine data as the master spindle. Special functions such as
thread cutting, tapping, revolutional feedrate, and dwell time apply to this spindle. For the
remaining spindles (e.g. a second spindle and an actuated tool) the numbers corresponding to
the speed and the direction of rotation / spindle stop must be specified.
Example:
Program code Comment
N10 S300 M3 S2=780 M2=4 ; Master spindle: 300 rpm, CW rotation
2nd spindle: 780 rpm, CCW rotation
Programmable switchover of master spindle
Fundamentals
2.6 Spindle motion
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 91
