Programming and Operating Manual (Turning)
292 01/2017
H
H0=
to
H9999=
H function ± 0.0000001 ...
9999 9999
(8 decimal places)
or specified as an
exponent:
± (10-300 ...
Value transfer to the PLC;
significance defined by the ma-
chine manufacturer
H0=... H9999=...
e.g.: H7=23.456
I Interpolation parame-
ters
±0.001 ... 99
999.999
Thread:
Belongs to the X axis; meaning
dependent on G2,G3 ->circle
center or G33, G34, G35 G331,
See G2, G3 and G33,
G34, G35
K Interpolation parame-
ters
±0.001 ... 99
999.999
Thread:
Belongs to the Z axis; others, as
with I
See G2, G3 and G33,
G34, G35
I1= Intermediate point for
circular interpolation
±0.001 ... 99
999.999
Belongs to the X axis; specifica-
tion for circular interpolation with
See CIP
K1= Intermediate point for
circular interpolation
±0.001 ... 99
999.999
Belongs to the Z axis; specifica-
tion for circular interpolation with
See CIP
L Subroutine; name and
call
7 decimals;
integer only, no
sign
Instead of a free name, it is also
possible to select L1
...L9999999;
this also calls the subroutine
(UP) in a separate block,
Please note: L0001 is not always
equal to L1.
The name "LL6" is reserved for
the tool change subroutine.
L.... ;separate block
M Additional function 0 ... 99
only integer, no
sign
For example, for initiating switch-
ing actions, such as "coolant
ON", maximum five M functions
M...
M0 Programmed stop The machining is stopped at the
end of a block containing M0; to
continue, press the following
key:
M1 Optional stop As with M0, but the stop is only
performed if a special signal
(Program control: "M01") is pre-
M2 End of main program with return to begin-
Can be found in the last block of
M30 End of program (as M2) Can be found in the last block of
M17 End of subroutine Can be found in the last block of
