SIREMOBIL Iso-C 3D SPR2-230.814.01 Page 6 of 14 Siemens AG
Rev. 05 08.04 CS PS 24 Medical Solutions
4 - 6 Kapitelüberschrift hier eintragen
• Fig. 15 shows the layout of the board D200.
• Disconnect plug D1.X3 from PC board D1. Connect the plug to connector D200.X103 on
interface PC board D200. Ensure proper locking.
• On D30, reconnect plug D30.X5 to D200.X115 on interface PC board D200. For this
purpose, slip the cable out of the existing shielding and reinsert it from the opposite side.
• On D30, reconnect plug D30.X12 to D200.X112 on interface PC board D200.
For this purpose, slip the cable out of the existing shielding and reconnect it to the
shielding at D200 (interface) (Fig. 16). Retighten the shielding on PC board D30.
Cable no. 3, item number n.a. 4
• Connect plug D30.X5 on D30 and plug-in location D200.X215 on D200.
Cable no. 4, item number n.a. 4
• Use ribbon cable no. 4 to establish the connection D200.X203 - D1.X3.
Cable no. 5A, item number n.a. 4
• Use ribbon cable no. 5A to establish the connection D200.X212 - D30.X12.
Cable no. 5B, item number n.a. 4
Without LITHOSTAR MODULARIS option:
• Use ribbon cable no. 5B to establish the connection D200.X211 - D30.X11.
With LITHOSTAR MODULARIS option:
• Cable no. 5B is not used (no replacement).
Cable no. 2, item number n.a. 4
• Disconnect plug D30.X4 on D30.
• Insert extension cable no. 2 at plug D30X4A to D30.X4.
• Insert plug D200.X114 on PC board D200.
Cable no. 1, item number n.a. 4
• Connect cable no 1. to plug D30.X4 on D30 and to plug D200.X214 on D200.
Cable no. 6, item number n.a. 4
• Connect cable no. 6 to plug D200.X220 on D200 and to D10.X12 on PC board D10.
Cable ties or shielding can be removed as required during the
installation.
After successful installation, the shielding must be reestablished
and the cables secured with the cable ties.
