SIREMOBIL Iso-C 3D SPR2-230.814.01 Page 14 of 14 Siemens AG
Rev. 05 08.04 CS PS 24 Medical Solutions
2 - 14 Actions up to serial number 1408
Centering disk, item no. 71 40 580 2
Washer, item no. Nr. 71 40 614 2
• Attach the washer and the centering disk at the cable module (see Fig. 33 and Fig. 34).
Do not use Loctite to secure other screws.
Fig. 33 Individual parts Fig. 34 Centering disk, fully installed up to serial number 1408
NOTICE
